Our range of services reflects our extensive know-how
Our extensive know-how in the field of refined quality steel opens up a wide range of applications in many areas of the automobile industry, the commercial vehicle sector and railway industry, mechanical engineering and plant construction, the energy sector and the construction industry. Customer-specific component properties have to be met for every application. We are your competent, experienced and flexible partner in every phase of your project. Our technical customer support also provides individual advice on materials and suitable alternatives. Ask our experts directly.
Our range of services provides you with a quick overview of our portfolio.
For your specific steel requirements, please use our inquiry form!
Steel and standards
| General construction steel | DIN EN 10025 |
| Steel for flame- & induction hardening | DIN 17212 (withdrawn) |
| Steel for quenching & tempering | DIN EN ISO 683-1 /-2 |
| Case hardening steel | DIN EN ISO 683-3 |
| Nitriding steel | DIN EN ISO 683-5 |
| Free-cutting steel | DIN EN 683-4 |
| Spring steel | DIN EN 10089 |
| Cold extrusion steel | DIN EN 10263 part 1-5 |
| Ball bearing steel | DIN EN ISO 683-17 |
| Chain steel | DIN 17115 |
| Tool steel | DIN EN ISO 4957 |
| AFP steel | DIN EN 10267 |
| Stainless steel | DIN EN 10088 part 1, part 3 |
| Type | Spectrum | ∅ min. | ∅ max. | length min. | length max. |
|---|---|---|---|---|---|
| HEAT TREATMENT | |||||
| Inductive surface hardening (+RSH) on single bar | surface hardening to defined hardening depths and surface hardness | 18,00 | 50,00 | 3000 | 8000 |
| Inductive quenching and tem-pering (+QT) on single bar | QT to target strength/structure specifications (tubes up to OD 50mm) | 18,00 | 70,00 | 3000 | 8000 |
| Inductive hardening (+Q) on single bar | Hardening to target strength/structure specifications | 18,00 | 70,00 | 3000 | 8000 |
| Conventional annealing in furnace | Target strength/structure specifications (+A, +AC, +FP, +N, +S, +TH, +SR, +CR) | 18,00 | 125,00 | 3000 | 8500 |
| BRIGHT STEEL PRODUCTION |
|||||
| Saws (bandsaw) | Sawing in bundles for standard lengths | 18,00 | 300,00 | 3000 | 8000 |
| Straightening | Straightness max. 2mm | 18,00 | 85,00 | 3000 | 8000 |
| Peeling and straight polishing | Toleranz field h9 acc. to DIN EN 10277 (straight polishing up to ∅ 80mm) | 18,00 | 125,00 | 3000 | 8000 |
| End machining | Chamfering/deburring/facing | 18,00 | 100,00 | 3000 | 8000 |
| Non-destructive material testing | Crack testing, ultrasonic testing, mix-up testing | 18,00 | 100,00 | 3000 | 8000 |
| Grinding | Toleranz field h6 up to h9 acc. to DIN EN 10277 | 18,00 | 60,00 | 3000 | 7800 |
| SHORT PARTS PRODUCTION |
|||||
| Saws (cold circular saws) | Fixed lengths | 18,00 | 90,00 | 20 | 2500 |
| End machining | Chamfering/deburring/facing/pivoting/centering/ brushing/signing/stamping | 18,00 | 90,00 | 20 | 2500 |
| Grinding | Tolerance field h6 up to h9 acc. to DIN EN 10277 | 20,00 | 35,00 | 500 | 1000 |
| Long turning | Contour machining | on request | |||
| Surface blasting | Medium: glass beads or on request | on request | |||
